Stax is our semi-automatic and fully automatic palletising of homogenous for your intralogistics.
Palletising
Systems
Stax

Automated picking of full cases

Full
case
PALLETISING

Stax is our product series for the semi-automated or fully-automated palletising of homogenous, in-line and layer-arranged pallets and roll containers, as well as mixed pallets and roll containers. The package products are packed fully-automated by robots according to a precomputed pattern and are made ready for despatch.

The result: Manual, arduous work steps in shop replenishment, often under extreme conditions (e.g. low-temperature refrigeration range), become obsolete.

Fully automatic palletising with TGW's Autostax palletising robot.
AutoStax-
Palletising
at Coop
Background Grid Invers
benefits

good
to
know

  • ZERO-TOUCH Thanks to full-automation, manual effort can practically be reduced to zero

  • FLEXIBLE ADAPTATION to your requirements thanks to expandability from the semi-automated to the fully-automated module

  • PROCESS OPTIMISATION thanks to direct palletising onto target loading equipment and subsequent completion using integrated foil winders, allowing individual process steps to be completely omitted

Stax

ProduCt-
wORLD

Our palletising modules are available in various configurations: from the semi-automated variant to the more cost-effective layer palletiser and even the fully-automated palletising system. A comprehensive add-on product range complements the portfolio.

LOADING FINGER

Fast and gentle handling of products according to a density-optimised stacking pattern

INTEGRATED FILM WRAPPING MACHINE

Optional integration of a film wrapping machine for shipping preparation

PALLET CHANGE

Maximum performance thanks to pallet change during wrapping

AutoStax

  • Fully automatic loading of pallets with mixed cartons
  • Load dimensions: up to 800 x 600 mm
  • Performance: up to 750 cartons per hour

SlotStax

  • Semi-automatic pallet loading (fully automatic provision and manual loading)
  • Cartons, totes, trays
  • Load dimensions: up to 800 x 600 mm
  • Performance: up to 1,200 units per hour

Multiple axes-Gantry Robot

  • Fully automatic loading using various gripper heads
  • Cartons, totes, trays
  • Can be designed as a gantry with two to five axes
  • Load dimensions: up to 1,200 x 1,000 mm
  • Performance: up to 600 cycles per hour

LAYER PALLETISER

  • Fully automatic layer palletising
  • Cartons, totes, trays
  • Load dimensions: up to 800 x 600 mm
  • Performance: up to 200 layers per hour

TowStax

  • Semi-automatic palletising (automatic provision and manual palletising)
  • Cartons, totes, trays
  • Load dimensions: up to 800 x 600 mm
  • Performance: up to 1,000 units per hour

Stacker

  • Fully automatic stacking of tote towers
  • Load dimensions: up to 600 x 400 mm
  • Performance: up to 800 totes per hour

INDUSTRIAL ROBOTS

  • Fully automatic handling using various gripper heads
  • Cartons, totes, trays
  • Load dimensions: up to 1,200 x 1,000 mm
  • Performance: up to 400 cycles per hour
